全口义齿数字化设计系统

韩景芸, 孙玉春

韩景芸, 孙玉春. 全口义齿数字化设计系统[J]. 北京工业大学学报, 2009, 35(5): 587-591.
引用本文: 韩景芸, 孙玉春. 全口义齿数字化设计系统[J]. 北京工业大学学报, 2009, 35(5): 587-591.
HAN Jing-yun, SUN Yu-chun. A Digital System for Complete Denture[J]. Journal of Beijing University of Technology, 2009, 35(5): 587-591.
Citation: HAN Jing-yun, SUN Yu-chun. A Digital System for Complete Denture[J]. Journal of Beijing University of Technology, 2009, 35(5): 587-591.

全口义齿数字化设计系统

基金项目:

国家自然科学基金资助项目(30772446).

详细信息
    作者简介:

    韩景芸(1977-),女,山东济南人,讲师.

  • 中图分类号: TP391;R783

A Digital System for Complete Denture

  • 摘要: 为了取代全口义齿传统经验型的手工制作方法,将数字化技术与中性区理论相结合,研发了全口义齿的数字化设计系统.该系统附带完全类型的人工牙数据库,采用“人工牙库=人工牙三维模型库+患者个性生物特征库”的知识结构描述方法,不仅重建了三维牙模,而且增了点、轴、坐标系等生理特征几何基准,建立起人工牙与选牙、排牙决策方案的相关性.排牙时,系统基于无牙颌模型的曲率特征,自动创建上前牙、下前牙、上后牙、下后牙的排牙线,同时制定了区域参数化排牙法则,实现了人工牙在排牙线上的个性化就位.最后基于特征曲面造型法,完成基托的设计.本系统以SCOLL语言为平台开发,界面友好,在任意设计阶段都可穿插人机交互,实现了个性、自动而又不失人性化的数字化设计流程.
    Abstract: The complete denture produced by traditional method is heavily relied on the skill and experience of the technician, with low quality and low effectiveness.A digital design system for complete denture that integrated technology and prosthodontical in neutral zone is described in this paper.The complete database is developed, including 3D artificial teeth models and geometrical features.Through extracting features on models of edentulous jaws, the system can automatically construct four teeth arrangement curves and create the orientation coordinate systems for every artificial tooth.Then the system can calculate the displacement matrix and realize teeth arrangement in teeth arrangement curves, after matching geometrical features of artificial teeth with orientation coordinate systems.The mixed modeling technology that blends triangle mesh and NURBS is implemented in base plate.The digital system is obtained based SCOLL with user-friendly human-computer interface and may become a new avenue for complete denture design.
  • [1]

    FABER B L.Comparison of an anatomic versus physiologic method of posterior tooth placement for complete dentures[J].J Prosthet Dent, 1992, 67:410-414.

    [2]

    DOUGLAS C W.Clinical practice-delivery of services:review of literature[J].J Prosthet Dent, 1990, 64:274-283.

    [3]

    CELEBIC A, VALENTIC-PERUZOVIC M.A study of the occlusal plane orientation by intra-oral method(retromolar pad)[J].J Oral Reh, 1995, 22:233-236.

    [4]

    STEPHEN G, RICHARD J.Using the neutral zone to obtain maxillomandibular relationship records for complete denture patients[J].J Prosthet Dent, 2001, 85(6):621-623.

    [5]

    LYNCH C D, ALLEN P F.Overcoming the unstable mandibular complete denture:the neutral zone impression technique[J].Dent Update, 2006, 33(1):21.

    [6] 王海鹰, 王秀芳, 谢玮, 等.中立区与齿槽嵴顶关系的深入研究[J].实用口腔医学杂志, 1997, 13(3):163-165. WANG Hai-ying, WANG Xiu-fang, XIE Wei, et al.The relation of the neutral zone position to the alveolar ridge crest[J]. Journal of Practical Stomatology, 1997, 13(3):163-165.(in Chinese)
    [7]

    TINSCHERT J, NATT G, HASSENPFLUG S, et al.Status of current CAD/CAM technology in dental medicine[J]. International Journal of Computerized Dentistry, 2004, 7:25-45.

    [8]

    SCHNEIDER W.Cerec 3D:a new dimension in treatment[J].Int J Comput Dent, 2003, 6(1):57-66.

    [9]

    MAEDA Y, MINOURA M, TSUTSUMI S, et al.A CAD/CAM system for removable denture.PartⅠ:fabrication of complete dentures[J].Int J Prosthodont, 1994, 7(1):17-21.

    [10]

    KAWAHATA N, ONO H, NISHI Y, et al.Trial of duplication procedure for complete dentures by CAD/CAM[J].J Oral Reh, 1997, 24(7):540-548.

    [11] 程祥荣, 华先明, 华中平, 等.计算机辅助全口义齿人工牙排列的研究[J].中华口腔医学杂志, 2000, 35(2):147-149. CHENG Xiang-rong, HUA Xian-ming, HUA Zhong-ping, et al.The study of a computer aided artificial teeth arrangement of complete denture[J].Chinese Journal of Stomatology, 2000, 35(2):147-149.(in Chinese)
    [12] 韩景芸, 李彦生, 费仁元, 等.基于逆向工程的标准牙冠模型的建立[J].北京工业大学学报, 2003, 29(2):141-143. HAN Jing-yun, LI Yan-sheng, FEI Ren-yuan, et al.Building of ideal dental crowns model based on reverse engineering[J].Journal of Beijing Polytechnic University, 2003, 29(2):141-143.(in Chinese)
