循环对称结构动应力计算的一种工程处理方法

秦飞; 张晓峰; 白洁; 魏建友; 陈立明

循环对称结构动应力计算的一种工程处理方法

1. 北京工业大学机械工程与应用电子技术学院, 北京 100022;
2. 中冶连铸北京冶金技术研究院, 北京 100081

详细信息

作者简介:
秦飞(1965-),男,河南巩县人,副教授。

中图分类号: TK262
计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2005-05-09
- 网络出版日期: 2022-12-29

A New Approach of Dynamic Stress Analysis for Cyclic Symmetry Structures

1. College of Mechanical Engineering and Applied Electronics Technology, Beijing University of Technology, Beijing 100022, China;
2. Continuous casting technology engineering Co. Ltd. of CMCC, Beijing 100081, China

摘要

摘要: 为了计算空冷汽轮机末级叶片的动应力,为工程设计提供依据。根据波传播理论和叶盘系统结构及其激振力特性,提出了求解瞬态动应力的循环对称计算方法。通过在扇区边界施加循环对称边界条件,将计算从时间域转化为空间域,间接实现了动应力计算,且在保证计算精度的前提下,提高了计算效率。
- 循环对称 /
- 动应力 /
- 空冷汽轮机 /
- 叶片
Abstract: The transient dynamic stress analysis by cyclic symmetry method was presented in this paper. According to the characters of blade structure and applied exciting force, the cyclic symmetry boundary displacement equation was established. The calculation of cyclic symmetry boundary displacement in time could be changed to calculation of space. The cyclic symmetry dynamic analysis could be realized by applying cyclic symmetry displacement on the boundary of blade sector.
- cyclic symmetry /
- dynamic stress /
- air cooling turbine /
- blade

HTML全文

参考文献(10)

[1]	MOTA C A, SCARES P M. Finite element dynamic analysis of practical discs[J]. Journal of Sound and Vibration, 1978, 61(4): 547-560.
[2]	THOMAS D L. Dynamics of rotationally periodic structures[J]. International Journal for Numerical Methods in Engineering, 1979, 14(1): 81-102.
[3]	张锦,王文亮,陈向钧.带有N条叶片的轮盘耦合系统主模态分析-Cnv群上对称结构的模态综合[J].固体力学学报,1984,5(4):469—481.ZHANG Jin, WANG Wen-liang, CHEN Xiang-you. Natural mode analysis of N blade disc coupled system-mode synthesis of symmetric structure with Cnv group[J]. Acta Mechanics Solida Sinica, 1984, 5(4): 469-481. (in Chinese)
[4]	王文亮,张锦,陈向钧.盘叶耦合系统的固有模态分析-CN群上对称机构的模态综合[J].固体力学学报,1988,9 (1):15—23.WANG Wen-liang, ZHANG Jin, CHEN Xiang-jun. Natural mode analysis of blades disc coupled system-odal synthesis of symmetric structure with C-N group[J]. Acta Mechanica Solida Sinica, 1988, 9(1): 15-23. (in Chinese)
[5]	赵宁,刘更.复约束方法计算斜齿圆柱齿轮结构特征值问题[J].航空动力学报,1996,11(2):133—137.ZHAO Ning, LIU Geng. Calculation of eigenproblems of helical gear structure by complex constraint methods[J]. Journal of Aerospace Power, 1996, 11(2): 133-137. (in Chinese)
[6]	李建中,王辉,岑章志,等.汽轮机带鳍状结构叶片组动力特性的有限元分析[J].工程力学,1997,14(4):68-71.LI Jian-zhong, WANG Hui, CEN Zhang-zhi, et al. Finite element analysis for dynamic behavior of group of stream turbine blade with fin heave[J]. Engineering Mechanics, 1997, 14(4): 68-71. (in Chinese)
[7]	黄海鹰,王建明.新型高推比涡轮风扇发动机盘也耦合振动分析[J].北京航空航天大学学报,1994,20(2):169-173.HUANG Hai-ying, WANG Jian-ming. Modal analysis of disc-blade coupling system of a turbofan aeroengine[J]. Journal of Beijing University of aeronautics and Astronautics, 1994, 20(2):169-173.(in Chinese)
[8]	周传月,皱经湘,闻雪友,等.燃气轮机带冠叶片耦合振动分析[J].哈尔滨工业大学学报,2001,33(1):129-133.ZHOU Chuan-yue, ZOU Jing-xiang, WEN Xue-you. Coupled vibrations of gas turbine shrouded blades[J]. Journal of Harbin Institute of Technology, 2001, 33(1): 129-133. (in Chinese)
[9]	何世江,杜建鋲,王勖成.水轮机转轮叶片系统动力分析[J].清华大学学报(自然科学版),1998,38(8):68-71.HE Shi-jiang, DUJian-bing, WANG Xu-cheng. Dynamic analysis of hydraulic turbine runner and blade system[J]. Journal of Tsinghua University (Science and Technology), 1998, 38(8): 68-71. (in Chinese)
[10]	PETROV E P. A method for using of cyclic symmetry properties in analysis of nonlinear multiharmonic vibrations bladed disks[J]. Journal of Turbomachinery(ASME), 2004, 126: 175-183.
