集成式电控单体泵特性及整机匹配

基金项目:

国防973资助项目（61357）.

详细信息

The IEUP Development on the Yunnei 4D44 Diesel Engine

1. College of Mechanical and Vehicle Engineering, Beijing Institute of Technology, Beijing 100081, China;
2. College of Envronment and Energy Engineering, Beijing University of Technology, Beijing 100124, China

摘要: 根据传统直列泵泵体结构设计了集成式电控单体泵燃油系统,实现在沿用发动机机体的条件下对柴油机进行改进;进行了集成式电控单体泵燃油系统在不同油管长度和不同转速下的特性试验.以YN4D44直列泵柴油机为对象,采用集成式电控单体泵燃油系统进行了整机改造,优化了喷油嘴流量,并进行了整机试验,结果表明,集成式电控单体泵燃油系统在高压油管过长、转速太高时性能将下降,集成式电控单体泵燃油系统应用于传统发动机改造能大幅提高排放性能.
- 柴油机 /
- 电控单体泵 /
- 仿真 /
- 排放
Abstract: To meet the needs of diesel engine industry, an IEUP fuel injection system was developed.In the IEUP, multiple EUPs were integrated into one inline-pump body to replace the traditional inline-pump.Based on experiments, the IEUP inject performance with different pipe length and engine speed was discussed.The IEUP was applied to an YN4D44 diesel engine and the inject flow was optimized in this paper.Experiments prove that the optimized IEUP diesel is highly improved.
- diesel /
- electronic unit pump(EUP) /
- simulation /
- emission

[1]	ROY M C.Evolution of diesel fuel injection equipment-the last 20 years[C/CD]//SAE.933015.
[2]	王尚勇, 杨青.柴油机电子控制技术[M].北京:机械工业出版社, 2005:34-35.
[3]	仇滔, 刘兴华, 刘福水.电控单体泵燃油系统凸轮型线优化研究[J].内燃机学报, 2008, 26(5):476-479. QIU Tao, LIU Xing-hua, LIU Fu-shui.The study for cam profile design of EUP[J].Transactions of CSICE, 2008, 26(5):476-479.(in Chinese)
[4]	白向东.IEUP柴油机排放控制优化研究[D].北京:北京理工大学, 2007. BAI Xiang-dong.IEUP diesel engine emission control optimization research[D].Beijing:Beijing Institute of Technology, 2007.(in Chinese)
[5]	初纶孔.柴油机供油与雾化[M].大连:大连理工大学出版社, 1989:133.
[6]	仇滔, 刘兴华.电控单体泵供油系统仿真研究[J].车用发动机, 2005, 4(2):23-25. QIU Tao, LIU Xing-hua.Simulation of the EUP fuel injection system[J].Vehicle Engine, 2005, 4(2):23-25.(in Chinese)
[7]	PÄR B, INGEMAR D.Diesel combustion with reduced nozzle orifice diameter[C/CD]//SAE.2001-01-2010.
[8]	CHAUFOUR P, MILLET G, HEDNA M, et al.Advanced modelling of a heavy-truck unit-injector system and its applications in the engine design process[C/CD]//SAE.2004-01-0020.
