Three-dimensional Scanning Probe Calibration Method
-
摘要: 为降低三维扫描测头中标定方法对测量系统定位精度的要求,提出了一种三维扫描测头标定方法,设计了一种最小二乘迭代算法及迭代数据筛选算法,实现了三维扫描测头高精度高效率的标定.为验证该三维扫描测头标定方法的稳定性与精度,设计若干组标定仿真实验,测试各类误差对于三维扫描测头标定结果的影响.结果表明:该三维扫描测头标定方法对于三维扫描测头标定过程中定位精度没有要求,对于测量机误差及扫描测头探测误差不敏感,三维扫描测头坐标系单位向量精度达0.000 01,完全满足三维扫描测头标定要求.Abstract: This paper proposes a three-dimensional scanning probe calibration method to reduce the positioning accuracy requirements.A fast least squares iterative algorithm and an iterative data filtering algorithm are designed to achieve the highly precise and efficient calibration of the three-dimensional scanning probe.Several calibration simulation experiments are designed to verify its stability and accuracy,and the influences on calibration result from various errors are tested.Experimental results show that this three-dimensional scanning probe calibration method does not require the positioning accuracy of measuring machine,it is insensitive to the measuring machine error and scanning probe detection error,the accuracy of unit vector of coordinate system of three-dimentional scanning probe reaches 0.000 01,and the three-dimensional scanning probe calibration requirements are completely satisfied.
-
Keywords:
- scanning probe /
- calibrattion /
- positioning accuracy /
- data filtering
-
-
[1] 石照耀,韦志会.精密测头技术的演变与发展趋势[J].工具技术,2007,41(2):3-8.SHI Zhao-yao,WEI Zhi-hui.Evolution and some trends inprecision probe technology[J].Tool Engineering,2007,41(2):3-8.(in Chinese) [2] 石照耀,张斌,林家春,等.坐标测量技术半世纪——演变与趋势[J].北京工业大学学报,2011,37(5):648-656.SHI Zhao-yao,ZHANG Bin,LIN Jia-chun,et al.Halfcentury of coordinate metrology technology—evolution andtrends[J].Journal of Beijing University of Technology,2011,37(5):648-656.(in Chinese) [3] WECKENMANN A,ESTLER T,PEGGS G,et al.Probing systems in dimensional metrology[J].Annals ofthe CIRP,2004,53(2):657-684.
[4] 孙涛,张龙江.坐标测量机高精度测头技术[J].制造技术与机床,2001(10):28-29.SUN Tao,ZHANG Long-jiang.High-precision probetechnology for CMM[J].Manufacturing Technology&Machine Tool,2001(10):28-29.(in Chinese) [5] 李明,费丽娜.几何坐标测量技术及应用[M].北京:中国标准出版社,2012:12-210. [6] 张美恋.基于遗传算法和单纯形法的混合优化算法[J].集美大学学报:自然科学版,2001,6(2):106-110.ZHANG Mei-lian.A hybrid optimizationbased on geneticalgorithm and simplex method[J].Journal of JimeiUniversity:Natural Science Edition,2001,6(2):106-110.(in Chinese) [7] 李春风,许承权,蒲文利.改进的单纯形法及其在非线性参数估计中的应用[J].海洋测绘,2009,29(6):14-16.LI Chun-feng,XU Cheng-quan,PU Wen-li.Improvedsimplex method for nonlinear least squares estimation[J].Hydrographic Surveying and Charting,2009,29(6):14-16.(in Chinese) [8] 王新洲.非线性模型参数估计理论与应用[M].1版.武汉:武汉大学出版社,2002:4-35. [9] 王新洲.非线性模型参数估计的直接解法[J].武汉测绘科技大学学报,1999,24(1):24-27.WANG Xin-zhou.A direct solution method of parameterestimation of nonlinear model[J].Journal of WuhanTechnical University of Surveying and Mapping,1999,24(1):24-27.(in Chinese) [10] 周明,孙树栋.遗传算法原理及应用[M].北京:国防大学出版社,1999:3-25.
