Classification of Frost Damage Grades in Tunnel
-
摘要: 为了给隧道冻害防治提供基本依据,通过分析隧道冻害发生的条件,选取气候和地下水条件作为等级划分的主要因素.在划分气候的寒冷程度和地下水危害程度的基础上,采用综合评判的方法,对隧道冻害等级进行划分.结果表明,气候和地下水条件是影响隧道冻害程度的最主要因素;气候条件选取最冷月平均气温和冻结深度2个控制指标,将隧道所处地区的寒冷程度划分为5级;地下水条件选取赋存与补给形式和渗入隧道情况2个指标,将地下水的危害程度划分为5级;综合考虑气候和地下水条件对隧道冻害程度的影响,将隧道冻害等级划分为5级;全多年冻土隧道的气候条件虽然更加恶劣,但是隧道处于含冰围岩中,常年处于冻结状态,冻害现象并不严重,只是在隧道开挖过程中人为影响或暖季促使围岩融化,冻害等级可划分为Ⅱ级.Abstract: In order to supply basic principles for preventing frost damage in tunnels,through analyzing the conditions of frost damage occurred in tunnels,climate and groundwater were chosen as main influencing factors to grading.On the basis of partition for climate cold level and groundwater harm degree,the classification of frost damage in tunnels is partitioned with a comprehensive evaluation method.The results show that the climate and groundwater are main influencing factors of frost damage;The cold level is partitioned into five grades by the control indicators of climate including the average temperature of the coldest month and the freezing depth;The harm degree of groundwater is partitioned into five grades by the control indicators of groundwater including the form of groundwater occurrence,supplying and the situation of groundwater spreading into tunnel.The classiffication of frost damage in tunnels is divided into five grades according to the influencing factors of climate and groundwater for frost damage levele;In permafrost,although the climate is cold in extreme,frost damage happens less seriously in the tunnels where surrounding rocks are freezing all the year round.The frost damage of permafrost tunnels is classified as grade Ⅱ while the ice on the surrounding rocks melts by the impacting of human activities in excavation or warming.
-
Keywords:
- tunnelling /
- frost damage /
- comprehensive evaluation
-
-
[1] 重庆交通科研设计院.JTG D70—2004公路隧道设计规范[S].北京:人民交通出版社,2004. [2] 罗鑫,夏才初.隧道病害分级的现状及问题[J].地下空间与工程学报,2006,2(5):877-880.LUO Xin,XIA Cai-chu.Current situation and problems of classification of yunnel diseases[J].Chinese Journal ofUnderground Space and Engineering,2006,2(5):877-800.(in chinese) [3] 铁道部第二勘测设计院.铁路工程设计技术手册:隧道[M].北京:中国铁道出版社,1995:240-245. [4] 田俊峰,杨更社,刘慧.寒区岩石隧道冻害机理及防治研究[J].地下空间与工程学报,2007,3(8):1484-1489.TIAN Jun-feng,YANG Geng-she,LIU Hui.Study on the freezing damage mechanism and its prevention in cold region rocktunnel[J].Chinese Journal of Underground Space and Engineering,2007,3(8):1484-1489.(in chinese) [5] 张德华,王梦恕.青藏高原永久冻土区隧道施工新技术[J].岩石力学与工程学报,2004,23(24):4234-4237.ZHANG De-hua,WANG Meng-shu.New technology for tunneling in permafrost in qinghai-tibet plateau[J].Chinese Journalof Rock Mechanics and Engineering,2004,23(24):4234-4237.(in chinese) [6] 周泰文,王晓星,刘后.模糊数学基础简明教程[M].武汉:华中理工大学出版社,1993:165-186. [7] 陈建勋.公路隧道冻害防治技术[J].长安大学学报:自然科学版,2006,26(4):68-70.CHEN Jian-xun.Technique of preventing frost damage in highway tunnel[J].Journal of Chang an University:Natural ScienceEdition,2006,26(4):68-70.(in Chinese) [8] 陈建勋,罗彦斌.寒冷地区隧道温度场的变化规律[J].交通运输工程学报,2008,8(2):44-48.CHEN Jian-xun,LUO Yan-bin.Changing rules of temperature field for tunnel in cold area[J].Journal of Traffic andTransportation Engineering,2008,8(2):44-48.(in Chinese) [9] 陈建勋,罗彦斌.寒冷地区隧道防冻隔温层厚度计算方法[J].交通运输工程学报,2007,7(2):76-79.CHEN Jian-xun,LUO Yan-bin.Calculation method of antifreezing layer thickness in cold region tunnel[J].Journal of Trafficand Transportation Engineering,2007,7(2):76-79.(in chinese)
