基于Verilog HDL的流水线模型机的设计与实现

详细信息

Design and Implementation of a Pipeline Model Machine Based on Verilog HDL

College of Computer Science, Beijing University of Technology, Beijing 100022, China

摘要: 为了提高模型机指令执行的并行性,使用Verilog HDL并采取top-down设计方法,利用确定的有限状态自动机(DFA)理论,设计并实现了一台具有指令级并行性的流水线模型机的方案.阐述了该流水线模型机的DFA设计算法与Verilog HDL的实现方法,并给出了相应的仿真测试.测试结果证明,该模型机能并行处理4条指令,并具有预取指令和旁路功能.
- 流水线 /
- VerilogH DL描述 /
- 微处理器 /
- 确定的有限状态自动机
Abstract: In order to raise parallelism of executing instructions by model machine,this paper introduces the schema of designing a pipeline model machine.Using Verilog HDL,a pipeline model machine with parallelism of instructions which is combined with top-down method and DFA is implemented.This paper describes the schema and some algorithms of the pipeline model machine and simulates this machine in the end.The simula- tion results show that the model machine can process 4 instructions at the same time,and has the per-for- mances of pre-fetching instructions and bypassing.
- pipeline processing /
- Verilog HDL descriptions /
- microprocessor chips /
- deterministic finite automation (DFA)
