板料拉延成形的数值模拟与网格试验法

基金项目:

北京市自然科学基金资助项目（3083018）；教委科技发展计划面上资助项目（KM200610011009）；北京市优秀人才培养资助项目（20061D0500300138）.

详细信息

Sheet Metal Forming Analysis With Numerical Simulation and Grid Experimental Method

1. School of Mechanical Automation, Beijing Technology & Business University, Beijing 100037, China;
2. Mechanical Department, Tsinghua University, Beijing 100084, China

摘要: 为了对板料拉延进行缺陷预测,在分析板料成形数值模拟和网格试验技术的基础上,采用数值模拟进行拉延成形分析,以及网格试验法进行成形缺陷成因判断,并将两者综合应用进行拉延成形缺陷预测和工艺优化的实例中.
- 数值模拟 /
- 有限元方法 /
- 板料成形 /
- 网格试验法
Abstract: To perform forming defect analysis and prediction of sheet metal parts, based on the study of numerical simulation and experimental method of sheet metal forming, a new approach which combined numerical simulation with grid experiment is proposed.The method to carry out shect meeal forming analysis with numerical simulation, and to perform forming defect analysis for specific local area with grid method is discussed in detail.By means of a practical case study, the approach for forming defect prediction and process optimization by utilizing numerical simulation method combined with experimental method is introduced. The result shows that it is an effective way to solve sheee metal forming defect problems by synthesizing numerical with experimental methods.
- numerical simulation /
- finite element method /
- sheet metal forming /
- gird experiment
